Reliable Electric Chain Hoist for Precision Lifting
When your project requires steady vertical movement and compact design, an electric chain hoist is the ideal solution. Unlike wire rope models, a chain hoist uses high-strength G80 or G100 lifting chains, which provide vertical lifting without the slight lateral movement (rope drift) common in drums.
At GT Winch, we manufacture chain hoists that are widely used in machine shops, assembly lines, and warehouse logistics. Our equipment is designed for durability, ease of installation, and maximum operator safety.
Electric Chain Hoist Technical Specifications
Explore our standard range of chain hoists to find the right match for your lifting needs:
| Model | Capacity (Tons) | Chain Diameter (mm) | Lifting Speed (m/min) | Power Supply | Motor Power (kW) |
|---|---|---|---|---|---|
| GT-CH005 | 0.5 Ton | 6.3 | 6.8 | 3-Phase AC | 0.75 |
| GT-CH01 | 1 Ton | 7.1 | 6.6 | 3-Phase AC | 1.5 |
| GT-CH03 | 3 Tons | 11.2 | 5.4 | 3-Phase AC | 3.0 |
| GT-CH05 | 5 Tons | 11.2 (Double) | 2.7 | 3-Phase AC | 3.0 |
| GT-CH10 | 10 Tons | 11.2 (Quad) | 2.7 | 3-Phase AC | 3.0 |
Mounting Options: Hook vs. Electric Trolley
-
Hook Type: Fixed in one position, ideal for stationary lifting stations.
-
Electric Trolley Type: Allows the chain hoist to travel along an I-beam, providing horizontal movement across a workshop.
Why Choose GT Winch for Your Lifting Equipment?
As a leading manufacturer, GT Winch integrates advanced technology into every hoist we build.
-
Safety First: Every unit includes overload protection, limit switches, and emergency stop functions.
-
Precision Control: Our hoists offer smooth start/stop features to prevent load swinging.
-
Global Standards: Our equipment complies with CE and ISO certifications, ensuring high quality for international markets.
FAQ: Chain Hoist
Q1: Can I use a chain hoist for outdoor applications? Yes, but we recommend adding a rain cover and ensuring the motor has an IP55 protection rating. GT Winch provides customized outdoor protection for every chain hoist.
Q2: What is the difference between a single-fall and double-fall chain hoist? A single-fall chain hoist uses one strand of chain for faster lifting speeds. A double-fall (or multi-fall) model uses multiple strands to lift heavier weights at a slower, more controlled speed.
Q3: How often should the lifting chain be replaced? The chain should be replaced if it shows signs of stretching (elongation), deep gouges, or significant rust. Regular lubrication with specialized chain oil significantly extends its life.
Q4: Do you offer single-phase electric chain hoists? Our standard industrial models are 3-phase, but we can provide 220V single-phase versions for lighter lifting tasks (usually up to 2 tons).
As a professional Industrial & Marine Winch Supplier, GT Winch offers
- Customizable Solutions – Available in various load capacities, speeds, and configurations to meet specific industrial requirements.
- High-Quality Manufacturing – Built with strict quality standards to ensure durability, reliability, and long service life.
- Low Maintenance Requirements – Engineered for minimal maintenance, reducing downtime and operational costs.
- General winches,marine winches,construction winches.etc available.Welcome to send a free inquiry.
OEM Supported
Email: info@gtwinch.com
-
Type of Winch-General Winch, Marine Winch, Mine Winch, or Other Type
-
Load Capacity-What is the maximum load (in tons or kilograms) the winch needs to handle?
-
Rope / Cable Type-What type of rope or cable will be used? (e.g., steel, synthetic)
-
Power Source-What type of power is required? (e.g., electric, hydraulic, pneumatic, manual)
