Precision Low Headroom Hoist for Space-Constrained Facilities
In many modern workshops and warehouses, ceiling height is a limiting factor. A standard hoist can take up significant vertical space, reducing your actual lifting range. The low headroom hoist from GT Winch is specifically engineered to solve this problem.
By reconfiguring the motor and drum layout, our low headroom hoist allows the hook to rise much higher than a conventional hoist, ensuring you can lift large loads even in confined environments.
Low Headroom Hoist Technical Specifications
Compare our standard low headroom models to see how much space you can save:
| Model | Rated Capacity (Tons) | Min. Headroom (mm) | Lifting Speed (m/min) | Traveling Speed (m/min) |
|---|---|---|---|---|
| GT-LH02 | 2 Tons | 350 – 450 | 8.0 | 20 (VFD Optional) |
| GT-LH05 | 5 Tons | 480 – 600 | 8.0 | 20 (VFD Optional) |
| GT-LH10 | 10 Tons | 650 – 850 | 7.0 | 20 (VFD Optional) |
| GT-LH20 | 20 Tons | 900 – 1100 | 3.5 | 18 (VFD Optional) |
Enhanced Safety Features
Safety remains our priority, even in compact designs:
-
Triple-Level Limit Switches: Prevents over-hoisting and ensures safe travel along the rail.
-
Frequency Inverter (VFD): Standard on many models to provide “soft start” and “soft stop,” reducing load swing in tight areas.
-
Heavy-Duty Rope Guide: Specifically reinforced for the offset weight distribution of low-profile lifting.
Why Choose GT Winch for Your Lifting Equipment?
As a leading manufacturer, GT Winch integrates advanced technology into every hoist we build.
-
Safety First: Every unit includes overload protection, limit switches, and emergency stop functions.
-
Precision Control: Our hoists offer smooth start/stop features to prevent load swinging.
-
Global Standards: Our equipment complies with CE and ISO certifications, ensuring high quality for international markets.
FAQ: Low Headroom Hoist
Q1: How much height can I save with a low headroom hoist? Depending on the capacity, a low headroom hoist can typically save between 200mm to 500mm of vertical space compared to a standard CD1 model wire rope hoist.
Q2: Is the maintenance different from a standard hoist? No. The core components (motor, gearbox, and wire rope) are similar. The primary difference is the physical arrangement. Regular lubrication of the offset gears and trolley wheels is recommended.
Q3: Can these hoists be used on both I-beams and H-beams? Yes, our electric trolleys are adjustable to fit various beam widths and profiles. Please provide your beam dimensions when ordering.
Q4: Do you offer customized colors or branding? Yes, we can provide customized paint finishes (standard is GT Yellow) and OEM branding for large-scale industrial projects.
As a professional Industrial & Marine Winch Supplier, GT Winch offers
- Customizable Solutions – Available in various load capacities, speeds, and configurations to meet specific industrial requirements.
- High-Quality Manufacturing – Built with strict quality standards to ensure durability, reliability, and long service life.
- Low Maintenance Requirements – Engineered for minimal maintenance, reducing downtime and operational costs.
- General winches,marine winches,construction winches.etc available.Welcome to send a free inquiry.
OEM Supported
Email: info@gtwinch.com
-
Type of Winch-General Winch, Marine Winch, Mine Winch, or Other Type
-
Load Capacity-What is the maximum load (in tons or kilograms) the winch needs to handle?
-
Rope / Cable Type-What type of rope or cable will be used? (e.g., steel, synthetic)
-
Power Source-What type of power is required? (e.g., electric, hydraulic, pneumatic, manual)
